nid-1 and emb-9 are the worm homologs of the human nidogen and human type IV collagen, respectively (Kramer, J. M. 2005). Nidogen is a glycoprotein that can bind type IV collagen with high affinity. nid-1 is single nidogen gene in the C. elegans genome, generating three alternative splice variants (nid-1A, nid-1B, and nid-1C) (Kang & Kramer, 2000). Type IV collagen is the principal component of basement membrane (BM), a complex network of triple helical molecules. emb-9 encodes sole α1-like type IV collagen that forms a heterotrimer with one α2-like type IV collagen (let-2). Nidogen and type IV collagen are components of BM that cover the basal surfaces of nearly all animal tissues. Previous work in C. elegans has confirmed the localizations of NID-1 and EMB-9 by using a transgenic strain or immunohistochemistry (Graham et al. 1997; Kim & Wadsworth, 2000) . To address endogenous localization patterns of both proteins in vivo, we used CRISPR/CAS9 technology to insert fluorescence label at the nid-1 and emb-9 genomic locus, and established worms expressing the mkate2::NID-1 or EMB-9::mcherry, respectively. To visualize all isoforms, nid-1A, B, and C, we inserted mkate2 into exon 2, which is a common exon for all isoforms. We found that mkate2::NID-1strongly localized to intestinal BM (Figure 1B and E) and localized to gonadal BM and nerve ring (Figure 1E and G), consistent with previous reports. Interestingly, we found that EMB-9::mcherry strongly localized to BM in pharynx (Figure 1D and F), although mkate2::NID-1 was faintly localized at pharyngeal BM (Figure 1E). We also confirmed strong expression of EMB-9::mcherry in coelomocytes, but not in the strain expressing mkate2::NID-1 (Figure 1G and H). The mkate2::NID-1 and EMB-9::mcherry are similarly localized to BM at gonad and uterus (Figure 1G and 1H). Differences of localization intensity at BM in the tissues are summarized in Figure 1G. Our work indicated that endogenous NID-1 and EMB-9 show different intensities at BM of pharynx, intestine, although it remains unclear whether these differences are associated with organ function.
N2 (Bristol) was used for the injection strain. Animals were cultured on standard NGM plate with E. coli (OP50) and maintained at 20 °C. To achieve genome-edited mkate2 knock-in nid-1 locus, we used pDD287 vector for repair template. pDD287 was modified to generate N-terminal mkate2::self-exiting cassette system repair template using following primers: 5’ nid-1 fwd AACGACGGCCAGTCGGATAATGTGAGTTTTTATCCAA, 5’ arm nid-1 rev GGCTCCCGATGCTCCAATTCCATTGTGTGAGAGAAAG, 3’ arm nid-1 fwd AGCGAGGAAGACTTGGTCGGTCTTGGAAAACCGACGC, and 3’ arm nid-1 rev CTATGACCATGTTATCTGATTATTGGACAAACTGAAA. DNA sequences of constructed vectors were confirmed by Sanger sequencing. To achieve genome-edited mcherry knock-in emb-9(xyz9[emb-9::mcherry]), we used PCR fragment for repair template. pJK750 (type IV collagen::mCherry expression vector) (Ihara et al, 2011) was used as PCR template using following primers: 5’ arm emb-9 fwd TAAGTTTGCAGTCGTTAGTAAAG, 3’ arm emb-9 rev AAGTTTGCAGTCGTTAGTAAAG. pDD162 (Peft-3::Cas9 + Empty sgRNA) vector from Bob Goldstein (Addgene plasmid # 47549) was used for Cas9 expression (Dickinson et al, 2013). The sgRNA plasmid was derived from Addgene plasmid 46169. For direct cleavage of target sequence, the following sgRNA sequences were used: 5’ CACAATGGAATTG/TCGGTCT 3’ for nid-1; and 5’AGAATTGTCAATCAA/GTTGC 3’ for emb-9. To prevent re-digestion after knock-in, fluorescence-tag was inserted into middle (/) position at sgRNA sequence at nid-1 and emb-9, respectively. The sgRNA vectors were microinjected together with 50 ng/µL pDD162, 50 ng/µL sur-5::gfp, and 50 ng/µL repair templates in N2 animals. Single mkate2::NID-1 was obtained based on roller phenotype, the SEC was excised as described (Dickinson & Goldstein, 2016). We selected candidate knock-in emb-9::mcherry strain, based on expression of EMB-9::mCherry, and confirmed the sequence of insertion sites. All images were acquired using an Axiocam 506 mono mounted on a Zeiss AxioImage A2 microscope equipped with a 20× Plan Apochromat objective lens that was controlled by ZEN 2.3 pro (Zeiss). Images were optimized and superimposed using Photoshop CS5 Extended (Adobe Systems).
Strain: IHR-168 xyz8[mkate2::NID-1]V
It will be sent to the CGC.
This work was supported by research grants from Ohsumi Frontier Science Foundation.
HistoryReceived: April 4, 2019
Accepted: April 18, 2019
Published: April 19, 2019
